Price
System
| Memory (Flash) | 4 GB |
| Memory (RAM) | 1 GB |
| CPU | Quad-Core RISC |
| RTC | Built-in |
I/O Ports
| HDMI Port | N/A |
| Wi-Fi | N/A |
| Ethernet/LAN | LAN 1: 10/100/1000 Base-T x 1; LAN 2: 10/100 Base-T x 1 |
| Audio Output | 1x Line Out / Built-in Mono Speaker |
| Video Input | N/A |
| Serial Ports | 2 |
| SD Card Slot | SD/SDHC (32GB capacity) |
| CANbus | Yes |
| USB Client Ports | N/A |
| USB Host Ports | USB 2.0 x 1 |
Display
| Resolution | 1024 x 768 |
| Luminance (cd/m^2) | 350 |
| Contrast Ratio | 2500:1 |
| Backlight Type | LED |
| Backlight Lifetime (hrs) | 70,000+ |
| Colors | 16.2 M |
| Display Type | 15″ WVA LCD |
| Size (W x H) | 12.05 x 9.06 inches [306 x 230 mm] |
| Viewing Angle (H°/V°) | 176/176 |
Touch Screen
| Type | Tempered Glass, Projected Capacitive |
Electrical
| Input Power | 31.2 W |
| Power Isolation | Built-in |
| Input Current | 1.3 A @ 24 VDC |
| Isolation Resistance | Exceed 50 MO – @ 500 VDC |
| Input Voltage | 24 ± 20% VDC |
Mechanical
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| Enclosure Material | Front bezel: Plastic, Rear Enclosure: Aluminum |
| PCB Coating | Yes |
| Dimensions WxHxD | 7.89 x 5.77 x 1.38 inches [200.4 x 146.5 x 35 mm] |
| Panel Cutout (inches) [mm] | 13.86 x 10.98 [352 x 279] |
| Weight | Approx. 6.06 lbs. [2.75 kg] |
| Mounting | Panel mount, VESA 75 x 75 mm |
Certifications
| UL Type Rating | UL Type 4X (indoor use only) |
| NEMA Rating | NEMA4 |
| IP Rating | IP66 Compliant Front Panel |
| CE | Yes |
| UL | cULus Listed |
| Class 1 Div 2 | N/A |
| RoHS | Yes |
